SPECIFICATIONS (RECEIVER) Wireless Format BOSS proprietary digital audio format Wireless carrier frequency 2.4 GHz Compatible Channels 14 (May vary due to local conditions) Transmission Range 65 feet line-of-sight (May vary due to local conditions) Latency 2.3 ms Dynamic Range 110 dB or greater Frequency Response 20 Hz--20 kHz Nominal Input Level -10 dBu Input Impedance 1 M ohm Nominal Output Level -10 dBu Output Impedance 1 k ohm Recommended Load Impedance 10 k ohms or greater Controls CABLE TONE switch (OFF/SHORT/LONG)
Indicators POWER RECEIVE
Connectors INPUT jack: 1/4-inch phone type OUTPUT jack: 1/4-inch phone type TRANSMITTER jack: 1/4-inch TRS phone type DC IN jack DC OUT jack
Power Supply Alkaline battery (AA, LR6) x 2 AC adaptor (sold separately)
Current Draw During wireless operation: 60 mA While charging transmitter: 320 mA
Expected battery life under continuous use Alkaline battery (AA, LR6): Approximately 10 hours ( These figures will vary depending on the actual conditions of use.)
Accessories Owner's Manual Leaflet USING THE UNIT SAFELY Transmitter Rubber foot x 4 Alkaline battery (AA, LR6) x 2 An AC adaptor (PSA-S series) is required to charge the transmitter (WL-T).
Options (sold separately) AC adaptor: PSA-S series Parallel DC cord: PCS-20A (DC Plug x8)
SIZE AND WEIGHT (RECEIVER) Width 72 mm 2-7/8 inches Depth 121 mm 4-13/16 inches Height 56 mm 2-1/4 inches Weight (including battery) 220 g 8 oz
Connectors Input plug: 1/4-inch TRS phone type DC IN 5 V port: USB Micro-B type
Power Supply Rechargeable lithium-ion battery Supplied from the DC IN 5 V port
Current Draw 350mA Battery charging time Approximately 3 hours Expected battery life under continuous use Approximately 12 hours (These figures will vary depending on the actual conditions of use.)
SIZE AND WEIGHT (TRANSMITTER (WL-T)) Width 87 mm 3-7/16 inches Depth 22 mm 7/8 inches Height 36 mm 1-7/16 inches Weight 43 g 2 oz
Brand reference number:WL-50
