Essential Information About the Ibanez AZ26P1 Premium Guitar
- Total versatility thanks to the Seymour Duncan Hyperion set in S?S?H configuration and the dyna?MIX9 system (9 tonal combinations with Alter Switch).
- Exemplary playing comfort: "Oval C" roasted maple neck, ebony fingerboard, jumbo stainless steel frets, Super All Access heel.
- Stability and precision: Gotoh T1502 vibrato, Gotoh MG?T locking tuners, Graph Tech nut.
- Premium craftsmanship: American basswood body, meticulous finishes, and included carrying case.
AZ: Ibanez?s Modern Take on the "Super S"
Designed to inspire, the AZ series has established itself as the contemporary benchmark for versatile guitars. The AZ26P1 belongs to the Premium range: selection of resonant woods, top-tier hardware, and ergonomics designed for today?s stages. Its "Super All Access" joint and generously contoured body promote smooth playing whether seated or standing.
Who Is This Guitar For?
Ideal for
intermediate to advanced guitarists seeking a unique instrument for studio and stage. From blues to rock, pop to modern metal, including fusion and funk, the S?S?H + dyna?MIX9 combination covers all bases: crisp clean tones, expressive crunch, and tight leads without changing guitars.
Sound
The American basswood body delivers a balanced and natural foundation, perfect for effects. The
Hyperion Alnico 5 pickups retain attack and clarity even under heavy saturation. The single coils provide precise highs and tight mids for funky rhythms; the bridge humbucker adds density and sustain for solos. The
dyna?MIX9 circuit expands the palette (splits and internal combinations) while the responsive and stable Gotoh T1502 vibrato keeps tuning accurate. The ebony fingerboard enhances quick response and articulation.
Recommended Compatible Accessories
-
10?46 nickel electric guitar string sets, ideal for the 25.5" / 648 mm scale length and intended tension level (e.g., the original factory set).
- Robust adjustable strap (leather or neoprene) and high-quality
6.35 mm jack cable to preserve dynamics.
- Stable guitar stand and microfiber cloth for routine maintenance of the finish and ebony fingerboard.
The guitar comes with a case, vibrato arm, and multifunction tool.
Technical Specifications
Body
- Type: Solid-body electric guitar
- Material: American basswood
- Finish: Gloss polyurethane
- Contours: Ergonomic forearm bevel and rear contour
Neck
- Neck type: AZ "Oval C" (bolt-on)
- Material: Roasted maple
- Finish: Satin polyurethane
- Thickness at 1st fret: 20.5 mm / 0.81"
- Thickness at 12th fret: 22.5 mm / 0.89"
- Scale length: 648 mm / 25.5"
- Nut width: 42 mm / 1.65"
- Width at neck end: 56.4 mm / 2.22"
- Number of frets: 22
- Fingerboard: Ebony
- Radius: 305 mm / 12"
- Frets: Jumbo stainless steel
- Inlays: Mother-of-pearl dots
- Side markers: Luminescent dots
- Nut: Graph Tech
Electronics
- Power: Passive
- Pickups: Seymour Duncan Hyperion S (neck), S (middle), H (bridge)
- Controls: 1 volume, 1 tone
- Selector: 5-position switch
- Additional switching: dyna?MIX9 with Alter Switch (9 combinations, including splits and humbucker simulation via 2 singles)
Hardware
- Vibrato bridge: Gotoh T1502 (steel saddles, die-cast zinc block)
- String spacing at bridge: 10.5 mm / 0.41"
- Tuners: Gotoh MG?T locking
- Hardware color: Gold
Miscellaneous
- Number of strings: 6
- String gauges: .010 / .013 / .017 / .026 / .036 / .046
- Original strings: D?Addario EXL110
- Factory tuning: Standard E (1E, 2B, 3G, 4D, 5A, 6E)
- Case / gig bag: Included carrying case
- Included accessories: Vibrato arm, multifunction tool
