Fender Tone Master Pro
The Tone Master Pro is the first no-compromise guitar multi-effects workstation, offering the incredible sound quality for which the Tone Master series is renowned, combined with a powerful, intuitive interface and I/O package that make Tone Master Pro the most powerful, powerful and easy-to-use guitar processor available. Tone Master Pro features over 100 of the world's most popular amps and effects, including all the classic Tone Master Fender models, the first officially licensed EVH 5150 III Stealth model, and other must-have classics, all of which have been perfectly reproduced using our exclusive Tone Master Modeling process.
7" COLOR TOUCHSCREEN
Large, easy-to-read color touchscreen for easy navigation and quick editing of all parameters.
ENCODER FOOTSWITCHES WITH DEDICATED DISPLAYS
Each footswitch features a dedicated LCD display and integrated rotary control for instant visualization of function and parameter settings.
6000+ VIRTUAL/FACTORY SPEAKERS
Precise speaker IR captured with a collection of classic studio microphones can be mixed and matched with any amplifier for infinite sonic possibilities.
Features:
- Controls :
- Navigation control
- Master volume control
- 10 footswitches/encoders with LCD "Scribble Strips" display
- Connectivity:
- USB-C®, Bluetooth
- MIDI: dual DIN 5-pin (merge input/output)
- Power requirement: 40W
- Input voltage range: 100-220 VAC, 50/60Hz
- Microphone input :
- XLR female (Combo), balanced; Impedance: 1.8 kΩ balanced
- Maximum preamp input level: 4.7 V
- Phantom power: +48 VDC (XLR only)
- Instrument input : 6.35mm jack
- Impedance: 1 MΩ, 330 kΩ, 22 kΩ configurable unbalanced
- Maximum level: 5.6 V (2.8 V with input attenuator disabled)
- Line input: 6.35mm TRS female jack (combo), balanced
- Maximum level: 7.8 V balanced, 4.5 V unbalanced
- Impedance: 1MΩ
- Auxiliary input :
- 3.5 mm stereo
- Impedance: 10 kΩ
- Maximum input level: 2.4V
- XLR and line outputs:
- XLR: XLR male, balanced (stereo pair)
- Line outputs: Jack 6.35mm TRS
- female, balanced (stereo pair outputs 1 and 2)
- Digital audio bit depth: 32-bit
- Supported sampling rate: 48 kHz internal (Project Sync 44.1/48/88.2/96 kHz)
- Digital audio frequency response: 20 Hz - 20 kHz (+0.1/-0.7 dB)
- Effect loops :
- 4 total - mono loops (1 and 2) Unbalanced 6.35mm jack, mono loops (3 and 4)
- Balanced 6.35mm TRS jack (can be combined as a stereo pair) ;
- Impedance: 10 kΩ
- Other connections :
- Expression pedal 1 and 2 6.35mm jack, amplifier control
- Power cable: IEC
- Dimensions: 96.4 x 371 x 262 mm
- Weight: 4 kg
Fender Tone Master FR-12
The Tone Master FR-12 is a full-range, flat-response amplified speaker designed for use with today's amplifier modelers and digital guitar profilers. The Tone Master FR-12 offers clear, precise sound reproduction, and perfectly reproduces every detail of amp and effects models. It's the perfect companion to the Tone Master Pro, and the ideal solution for guitarists using modeling equipment at home or on stage.
The Tone Master FR-12 features a 1,000-watt power amp that delivers the volume and power reserve needed for the most demanding gigs.
An active 3-band EQ and high-frequency cutoff allow musicians to fine-tune their sound on stage without altering the line-out signal. What's more, the design of the FR series was inspired by classic Fender amplifiers for an authentic backline look and feel.
Features :
- Series: Tone Master
- Output power: 1,000 watts
- Speaker type: 2-way active
- LF transducers: 12-inch Special design
- HF transducers: 1 inch Compression
- Inputs: Combo jack 6.35mm / XLR
- Channels: One
- Controls: Volume, treble, midrange, bass, mute
- Line output: One - XLR with Ground Lift
- Output level
- Output level: 130 dB
- Frequency range: 58 Hz - 20 kHz (-10 dB)
- Frequency response: 75Hz - 20kHz (-3dB)
- Cabinet material: Lightweight plywood
- Dimensions: 251 x 461 x 597 mm
- Weight: 12.7 kg
