K7YIN
When Ibanez shocked the world and released the first 7-string electric guitar 30 years ago, little did anyone realize then just how much the instrument would change guitar-driven music forever. Korn were arguably the first musical act to take these instruments and realize their full sonic potential, shaping a sound that would be responsible for creating whole new movement in music. Korn and Ibanez designed the K7 signature model in the early 2000s, creating an instrument that was able to match Korn’s unparalleled uniqueness.
Product Features
Wizard II-7 5pc Maple/Walnut neck
Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.
Ebony fretboard w/ K-7 special inlay on 11th to 13th fret
Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.
Jumbo frets
Jumbo frets contribute to smooth playability, especially for single-note playing.
Okoume body
The Okoume body provides a bright and solid sound.
DiMarzio Blaze H-H pickups
DiMarzio Blaze pickups were first introduced for our Universe guitars. With a scooped mid-range and just-right output level, they can handle everything from jazzy-clean tone to heavily distorted sound.
Gotoh machine heads
Gotoh machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.
Lo-Pro Edge tremolo
The legendary Lo-Pro Edge bridge offers maximum playing comfort with its streamlined profile and recessed fine tuners. Locking studs contribute to tuning stability.
Luminescent side dots
The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
SWITCHING SYSTEM
When the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is in the center position, both pickups are selected. When the switch is in the bridge position, the bridge pickup is selected.
CONTROLS
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the three-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
Specifications
Body
Neck
- Neck Type : Wizard II-7
- Neck Joint : Bolt-on
- Neck Material : Nyatoh
- Neck finish : Satin Polyurethane
- Neck thickness (1st fret) : 19 mm
- Neck thickness (12th fret) : 21 mm
- Scale : 25,5 inch / 648 mm
- Nut width : 1,89 inch / 48 mm
- End width : 68 mm
- Number of fret : 24
- Fret type : Jumbo
- Fretboard : Ebony
- Fretboard Radius : 15,75 inch / 400 mm
- Inlay : K-7 special inlay on 11-13th fret
Hardware
- Bridge : Lo-Pro Edge
- String spacing : 10,8 mm
- Nut : Locking
- Machine Head : Gotoh machine heads
- Hardware color : Black
Electronics
- Neck Pickup : DiMarzio Blaze (H)
- Bridge Pickup : DiMarzio Blaze (H)
- Controls, Pickup selector : 1 Volume, 1 Tone, 3-way lever switch
- Active or Passive : Passive
Miscellaneous
- String Gauges : .010/.013/.017/.026/.036/.046/.059
- Special Strings : D'Addario EXL110-7
- Tuning : 1D,2A,3F,4C,5G,6D,7A
- Other item(s) included : Tremolo arm, Hex wrench
