The torrefied maple neck is heat-treated to increase stability, durability, resistance to humidity, and tolerance to temperature changes.
Jatoba Fingerboard
Jatoba has a reddish-brown color and produces a rich midrange with a bright high end.
Jumbo Stainless Steel Frets
Stainless steel frets offer excellent corrosion resistance. The wide and tall frets provide quick response and effortless articulation when playing chords, as well as a clear tone when playing single notes.
Locking Machine Heads
Locking tuners ensure precise and stable tuning.
Quilted Maple Top / Alder Body
The quilted maple top features a beautiful wood grain. The alder body offers a clear and balanced tone, enriched resonance, and sustain.
Ibanez Modern Custom Pickups
The Ibanez Modern Custom pickups feature a dual humbucker configuration with Alnico V magnets. They deliver a powerful sound and quick response, which pair especially well with overdrive and distortion.
T106 Tremolo
The T106 tremolo bridge with 6 individual saddles allows precise adjustment of each string’s height and intonation.
dyna-MIX10 Switching System with Alter Switch
The dyna-MIX 10 offers ten tonal variations and allows easy switching between humbucker and single-coil modes via the mini toggle switch. The power tap mode provides a realistic single-coil sound despite its dual humbucker pickup layout.
Super All Access Neck Joint
The Super All Access Neck Joint enhances playability and allows easy access to the highest frets.
Specifications:
Neck type: AZ / torrefied maple neck
Top, back, and body: Quilted maple top / alder body
Fingerboard: Jatoba fingerboard / white dot inlays
Frets: Jumbo stainless steel
Number of frets: 24
Bridge: T106
String spacing: 10.5mm
Neck pickup: Ibanez Modern Custom (H) (Passive/Alnico)
Bridge pickup: Ibanez Modern Custom (H) (Passive/Alnico)
Factory tuning: 1E, 2B, 3G, 4D, 5A, 6E
String gauge: .010/.013/.017/.026/.036/.046
Hardware color: Chrome
Neck Dimensions
Scale length: 648mm / 25.5"
a: Width: 42 mm at the nut
b: Width: 57 mm at the 24th fret
c: Thickness: 20.5 mm at the 1st fret
d: Thickness: 22.5 mm at the 12th fret
Radius: 305mmR
Guitar Neck Diagram
a: Neck width at the nut
b: Neck width at the first fret
c: Neck thickness at the first fret
d: Neck thickness at the twelfth fret
Radius: Fingerboard radius
Other Features
Recommended gig bag: IGB540-BK
Brand reference number:AZ24S1FTKS
