General- Manual turntable USB- Belt drive- Built-in RIAA phono preamp (bypassable)- DC motor- Rotation speed: 33-1/3 rpm, 45 rpm- Rotation speed variation: +/-2%- Wow and flutter: 0.2%- Signal-to-noise ratio: 67 dB or higher (A-weighted, 20 kHz LPF) / 60 dB or higher (unweighted, 20 kHz LPF)- Finish: Glossy woodPlatter- Die-cast aluminum- Equipped with a damping ring- Platter diameter: 12" (300 mm)- Rubber mat includedTonearm TP 71- Design: aluminum tube- Type: straight, static balance- Effective length: 8.8" (223.6 mm)- Tracking force: 0 to 4 g- Recommended cartridge weight: 3.5 to 6.0 g- Overhang: 18.6 mm- Adjustable anti-skating- Headshell weight: 10 g (nuts, bolts, and cables included)Tonearm- Design: aluminum tube- Type: straight, static balance- Effective length: 8.8" (223.6 mm)- Tracking force: 0 to 4 g- Recommended cartridge weight: 3.5 to 6.0 g- Overhang: 18.6 mm- Compatible with anti-skating adjustment- Headshell weight: 11 g (nuts, bolts, and cables included)Cartridge- Model: Audio-Technica AT95E- Elliptical diamond- Aluminum cantilever- Frequency response: 20 Hz to 20 kHz- Channel separation: 20 dB at 1 kHz- Channel balance: 2 dB- Output voltage: 4 mV at 1 kHz, 5 cm/sec- Vertical tracking angle: 23°- Tracking force: 1.5 to 2.5 g (standard 2 g)- Static compliance: 20 x 10^-6 cm/dyne- Dynamic compliance: 6.5 x 10^-6 cm/dyne (100 Hz)- Coil material: TPC copper- Recommended load impedance: 47 kOhms- Recommended load capacitance: 100-200 pF- Coil inductance: 400 mH at 1 kHz- Cartridge weight: 5.7 g (+/- 0.5 g)Connectivity- Stereo analog audio output: gold-plated RCA connectors- USB output: use a USB cable to connect your turntable to your computerPower supply- Mains voltage: AC 100 - 240V, 50/60Hz- Power consumption: 1.5 W (less than 0.5 W in standby)Logistics data- Dimensions (W x H x D): 420 x 355 x 121 mm- Weight: 3.9 kg
Brand reference number:
9200_TD_202_WA
