- Type: MM (Moving Magnet)
- Diamond: Nude Tip / Line Contact
- Output voltage at 1000 Hz, 5 cm/sec: 5 mV
- Channel balance at 1 kHz: 1 dB
- Channel separation at 1 kHz: 26 dB
- Channel separation at 15 kHz: 15 dB
- Frequency response: 20-20,000 Hz (+2 / -0 dB)
- Tracking ability (315 Hz with recommended tracking force): 80 µm
- Compliance, dynamic, lateral: 22 µm/mN
- Stylus tip radius: r/R 8/40 µm
- Tracking force range: 1.4-1.7 g (14-17 mN)
- Recommended tracking force: 1.5 g (15 mN)
- Tracking angle: 20°
- Internal impedance: 1.2 ohms
- Internal inductance: 630 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacitance: 150-300 pF
- Cartridge and stylus color: Black/Bronze
- Weight of 2MR cartridge: 6 g
- Weight of Verso 2M and 2M cartridges: 7.2 g
- Weight of pre-mounted 2M cartridge: 16.7 g
- Replacement diamond: 2M Bronze (interchangeable with 2M Black and 2M Black LVB 250)
Brand reference number:
9030_2M_BRO
