- Type: Low-level MC (Moving Coil) - Diamond: Spherical - Cantilever: Aluminum - Mounting: Arm with SME connection - Output voltage at 1000 Hz, 5 cm/sec: 0.18 mV - Channel balance at 1 kHz: 1.5 dB - Channel separation at 1 kHz: 20 dB - Channel separation at 15 kHz: 10 dB - Frequency response: 20-20,000 Hz ± 3 dB - Tracking capacity (315 Hz with recommended tracking force): 60 µm - Dynamic lateral compliance: 10 µm/mN - Stylus tip radius: R 18 µm - Tracking force range: 3.0-5.0 g (30-50 mN) - Recommended tracking force: 4.0 g (40 mN) - Tracking angle: 20° - Internal impedance, DC resistance: 2 ohms - Recommended load impedance: > 10 ohms - Cartridge body material: Composite of ground wood and resin - Coil wire material: High purity copper (OFC) - Cartridge color: Matte black - Cartridge weight: 28 g
