Key Features of the Casio Privia PX?S1100 Digital Piano (Blue)
- Ultra-compact 88-key hammer action keyboard (232 mm depth, 102 mm height) without compromising playability
- Expressive touch with ?scaled hammer action,? synthetic ivory/ebony textures, and Digital Scaling technology, hammer response, and key release response
- Expressive AiR sound engine, 192-note polyphony, 2 x 8 W amplifier system, and 16 x 8 cm speakers
- Modern connectivity: wireless audio & MIDI adapter WU?BT10 included, USB, line outputs, dual headphone jacks
The Ultra-Compact Vision of the Privia Series
Within the Casio Privia range, the PX?S1100 embodies a slim and elegant portable piano designed to fit anywhere. Its high-density design reduces footprint while preserving the touch, expressiveness, and sound projection of an instrument suited for both stage and home use.
Keyboard Design
88-key scaled hammer action keyboard with
5 sensitivity levels and
synthetic ivory/ebony key surfaces for natural grip. The
Digital Scaling 88-key finely adjusts volume and resistance key by key, while the
hammer response and
key release response refine timing and articulation from legato to staccato.
Half-pedal compatibility with the optional SP?34 3-pedal unit.
Sound Quality
Powered by the
AiR sound source (multidimensional samples), the PX?S1100 offers
18 tones and a
192-note polyphony. Its
2 x 8 W system drives two
16 x 8 cm speakers for wide sound dispersion. The acoustic simulator provides string and damper pedal resonance, as well as mechanical noises for an immersive grand piano experience.
Built-in Effects
Reverb (room simulator), Surround, chorus,
brightness control, and preset
DSP effects optimize spatial depth, width, and timbre presence.
Educational Features
Ideal for learning:
metronome,
Duo/four-hand mode,
layer/split, 60 built-in songs, and
lesson function with start/stop by hand.
2-track MIDI and
audio recorder to capture your ideas, dual headphone outputs for silent practice, and USB playback/recording.
Advanced Functions
- Bluetooth audio & MIDI via included WU?BT10 adapter (A2DP/SBC, MIDI BLE): streaming from smartphone/tablet and wireless MIDI control
- USB Type B/Type A: MIDI/DAW interface and storage (playback/recording)
- Stereo line outputs, 2 headphone jacks, pedal input, and 3-pedal unit port
- Transposition, fine tuning, temperaments, Layer/Split modes, and battery power option for mobility
Technical Specifications
Keyboard
- Scaled hammer action keyboard
- Number of keys: 88
- Touch response: 5 levels, off
- Finish: white keys with ivory texture, black keys with ebony texture
- Digital Scaling 88-key technology
- Hammer response, key release response
- Half-pedal support with SP?34 (optional)
Sounds
- Audio source: AiR multidimensional sound engine
- Polyphony: 192 notes
- Number of tones: 18
- Acoustic simulator: string resonance (4 levels, off), damper pedal resonance (4 levels, off), key action noise (4 levels, off), damper pedal noise (4 levels, off)
Effects
- Room simulator: 4 types, off
- Surround: 2 types, off
- Chorus: 4 types, off
- Brightness: -3 ~ 0 ~ +3
- Digital signal processing: presets for certain tones
Educational Features and Library
- Included songs: 60; demo song: 1
- Lesson function: start/stop by hand (right hand, left hand)
- Song addition: up to 10 songs (approx. 90 KB per song)
Recording
- MIDI recorder: 2 tracks, 1 song; approx. 10,000 notes total; real-time recording and playback
- Audio recorder: up to 99 songs, approx. 25 minutes per song
Modes and Settings
- Layer/Split: Yes
- Four-hand (Duo) mode: Yes
- Octave shift: -2 ~ 0 ~ +2
- Transposition: -12 ~ 0 ~ +12 semitones
- Tuning: A4 = 415.5 Hz ~ 440.0 Hz ~ 465.9 Hz
- Temperaments: equal temperament + 16 variations
- Metronome: 0 to 9 measures; tempo 20 to 255
- Auto power off: Yes
Pedals
- Included: SP?3 (1 jack)
- Optional: SP?34 (damper, soft, sostenuto pedals)
- 3-pedal unit connector: Yes (SP?34)
Amplification and Sound Output
- Speakers: 16 cm x 8 cm (oval) x 2
- Amplifier power: 8 W + 8 W
- Headphone/output jacks: 2 (stereo mini jack)
- Line outputs: 2 (left/mono, right), standard jack
Connectivity and MIDI
- USB: Type A, Type B
- Pedal: 1 (damper pedal)
- MIDI: Yes (via wireless adapter or USB port)
Bluetooth and Applications
- Wireless audio & MIDI adapter: WU?BT10 included
- Bluetooth version: 5.0
- Audio profile: A2DP (SBC codec)
- MIDI profile: GATT (MIDI over Bluetooth Low Energy)
- Compatible app: CASIO MUSIC SPACE
Power Supply
- Dual power supply: batteries/AC adapter
- Batteries: 6 AA alkaline batteries; approx. 4 hours battery life
- AC adapter: AD?A12150LW (12 V DC)
- Power consumption: 10 W
Dimensions and Weight
- Dimensions: 1,322 x 232 x 102 mm (without music rest)
- Weight: 11.2 kg (without batteries)
Color
Package Contents
- Wireless MIDI and audio adapter (WU?BT10), pedal (SP?3), music rest, AC adapter (AD?A12150LW)
