Emblematic of the very high-performance cards offered by RME, the HDSPe MADI FX is part of the very complete family of RME MADI solutions. The HDSPe MADI FX offers 390 audio channels via three MADI inputs/outputs, and also offers an AES/EBU I/O port and a stereo monitoring output. Equipped with a new Hammerfall Pro Audio Core, it integrates TotalMix FX, a true routing and effects center. To guarantee RME's unique latency performance despite such a number of audio channels, the HDPSe MADI FX introduces a new modular Hammerfall Pro Audio Core, specially developed for the product. This core can handle three times more channels than previous RME MADI cards, while reducing the system load and ensuring ultra-low latencies (up to 32 samples on a recent computer).
Features: - PCI Express audio interface card - MADI: 194x input channels and 194x output channels - Analog outputs: 2x channels (6.3 mm stereo jack, monitoring or headphones) - 4096x mono channel matrix router - Optical MADI to coaxial converter functionality - AES / EBU interface for direct integration of converters - Extremely low latency - Sample rates up to 192 kHz - SteadyClock - Digicheck: measurement and analysis tool (EBU R128 compatible) - TotalMix routing software - Internal 42-bit signal router - Integrated DSP effects - 2x optical MADI inputs and outputs - 1x coaxial MADI input and output - 1x AES / EBU input and output - 1x stereo analog output (headphones) - 1x Word Clock input and output - 1x MIDI input and output via 5-pin DIN - 3x MIDI inputs and outputs via MADI
