The SUB 702-AS mk3 is an active subwoofer with 12” high power for live sound applications. It has a sophisticated speaker. &àgrave; ceramic magnet and a powerful Class D amplifier, ensuring sound pressure levels reaching 129 dB SPL, with exceptional dynamic range. Designed as the ideal complement to 8? speakers. or 10”, it delivers exceptional performance in all applications. The controls are grouped on the rear panel: volume, EQ, audio polarity. and selection of the cutoff frequency. The robust all-wooden box, equipped with A scratch-resistant polyurethane coating makes it durable, facilitates transport and allows for secure installation. Thanks to its versatility, its quality; With its high sound and high pressure, the SUB 702-AS MK3 is perfect for small to medium sized rooms and traveling applications.
A legendary subwoofer
RCF subwoofers are the preferred choice ; many sound engineers, thanks to their very high sound pressure level in very low frequencies, their dimensions less than those of their competitors, their amplified design, their reliability and their reliability. &àgrave; long term and their impressive size/weight/SPL ratio. They will immerse your audience in an immersive and compelling sound experience in live sound and DJ applications.
Power that moves
The improvements made by RCF to its speakers make them more solid and powerful, and the amplification naturally accompanies this evolution. With a peak power of 1400 W, the integrated Class D amplifier allows you to generate extreme pressure levels with ultra-fast attack, realistic transient response and very low heat-up. The design of the sub is highly efficient. Energy efficient, there is no need to use a cooling fan. The amp is fixed &àgrave; a solid aluminum heatsink with no moving parts, located at the bottom &àgrave; the back of the box. The stereo input circuit with its active filter is a new design, ensuring low distortion. An advanced limiter preserves the naturalness of the incoming signal, all levels. All RCF amps are designed to EN62368-1 for maximum safety. maximum, and their food at agrave; cutting combines efficiency high and minimum weight.
SUB 7 Series subwoofers can be configured to suit your needs. from the rear panel and feature very comprehensive controls:
- CROSSOVER PRESET 80 Hz/120 Hz
- POLARITY INVERSION
< p>- OUTPUT SIGNAL, LINE / HIGH PASS
Bass Motion Control
In order to extend the bass response and improve performance, RCF engineers found a new solution. the way to remove the high-pass filter, replacing it with an innovative approach. Introducing BMC (Bass Motion Control), a new advanced bass processing. management of the bass speaker excursion. The speaker equipped with BMC processing can handle the lowest audible frequencies without affecting the stability of the speaker. of the bass speaker, with linearity extension and a more faithful rendering. The BMC processing approach relies on the complete mapping of the dynamic behavior of the bass driver, in order to generate a specific algorithm that limits only excessive excursions. It therefore leaves freedom total reproduction of the signal to the loudspeaker. Normally used low-cut filters reduce the amount of travel that can damage the bass driver, but they also change the phase response. The new BMC treatment allows you to overcome this rule.
A workhorse on tour
The subwoofer is suitable for very varied live sound applications. Thanks to its lightness, the robust plywood box makes it easy to use. is easy to use transport and transport stack. All subwoofers are equipped with ergonomic rubber-covered handles for easy assembly and disassembly. The M20 threaded base on the top allows the sub to accommodate speakers with a foot base. The ultra-resistant polyurethane coating, the powder-coated metal grille and the robust structure of the box resist to damage. intensive use as well as transport constraints. The separate housing for the amp guarantees efficiency and reliability components. Acoustically transparent foam behind the grille provides protection against dust and humidity. Thanks to Thanks to its front vents, the subwoofer can also be used separately. in recessed spaces.
ACOUSTIC SPECIFICATIONS
SPEAKERS
INPUTS / OUTPUTS SECTION
PROCESSOR SECTION
POWER SECTION
PHYSICAL SPECIFICATIONS
SIZE
