Description
OSCILLATORS 2 digitally controlled analog oscillators (DCOs) per voice (plus sub octave on oscillator 1) with selectable sawtooth, triangle, saw/triangle mix, and pulse waves (with pulse-width modulation) Glide (portamento): separate rates per oscillator White noise generator Analog VCAs Hard sync
FILTERS 1 analog Curtis low-pass filter per voice, selectable 2- and 4-pole operation (self-resonating in 4-pole mode)
ENVELOPES 3 envelope generators: filter, VCA, and assignable (four-stage ADSR + delay); Envelope 3 can loop.
SEQUENCER Polyphonic step sequencer with up to 64 steps (6 notes per step), and ties and rests. Separate 16 x 4 gated step sequencer. Each layer can have a separate sequence.
LFOS 4 LFO’s with key sync per LFO
MODULATION 8-slot modulation matrix
ARPEGGIATOR Programmable arpeggiator with up, down, up+down, random, assign modes Selectable note value: 16th note, 8th note triplet, 8th note, dotted 8th note, quarter note One, two, or three octave range Re-latching arpeggiation Note repeat
CONTROLS 5-octave keyboard with semi-weighted action, velocity, and aftertouch 52 knobs and 20 buttons enable deep and comprehensive editing with little to no menu diving. Spring-loaded pitch wheel and assignable mod wheel
MEMORY 512 Factory Programs (4 banks of 128) and 512 fully editable User Programs with 2 layers (2 separate sounds) in each Program
IN/OUT MIDI In, Out, Thru Main stereo audio output: 1/4″ unbalanced Output B stereo audio output: 1/4″ unbalanced Sustain pedal input: accepts normally on or normally off momentary footswitch. Pedal/CV input: responds to expression pedals or control voltages ranging from 0 to 5 VDC (protected against higher or negative voltages). Headphone output: 1/4″ stereo phone jack.
POWER IEC AC power inlet for internal power supply Operates worldwide on voltages between 100 and 240 volts at 50 to 60 Hz; 30 watts maximum power consumption
PHYSICAL SPECS Oiled African mahogany wood end panels Dimensions: 12.70″ (32.26 cm) W x 35.12″ (89.20 cm) L x 3.80″ (9.65 cm) H (2.30″ at front edge; the feet account for 0.25″ of the total height) Weight: 20.5 lbs. (9.3 kg)
